DraftSight
Professional-grade 2D CAD drafting and 3D design software for creating, editing, and viewing DWG files
About DraftSight
- Create, edit, view, and markup 2D and 3D DWG, DXF, and DGN files with precision and efficiency.
- Supports advanced features like STEP import, DGN export, and enhanced visibility control for custom blocks.
- Integrates seamlessly with SOLIDWORKS and 3DEXPERIENCE platforms for streamlined collaboration and data management.
- Offers productivity tools such as Dynamic Blocks, PowerTrim, DrawCompare, and automatic layer assignment.
- Provides flexible licensing options, including named-user, network, and perpetual licenses.
- Includes a familiar AutoCAD-like interface, supporting LISP routines and custom scripts for easy transition.
- Enables 3D modeling, parametric constraints, and prototyping for manufacturing and laser cutting.
- Features a Block Structure Palette and enhanced Dimension Style Manager for simplified design workflows.
Technical Specifications
Platforms
Windows, macOS
Latest Version
DraftSight 2025
License Type
Subscription
Pricing
Professional
$299.00
Per year
- Create, view and edit DWG, DXF and DGN files
- Powerful and affordable 2D drafting for everyone
- Complete set of edit, design and automation tools (incl. Autolisp)
Premium
$599.00
Per year
- Manage large 2D drawing sets with Sheet Set Manager
- Save time with PDF Import and batch printing
- Advanced 2D drafting and 3D design with parametric constraints
Network
$399.00
Per year
- Activate simultaneous usage and compliance throughout the organization
- Complete technical support provided by SOLIDWORKS partners
- Save time with easy network license deployment
